Description
CONSTRUCTION
- Welded tank with an extra smooth peened finish ensures easy cleaning.
- Long lasting, high temperature alloy stainless steel heat baffles are mounted in the heat exchanger tubes to provide maximum heating and combustion.
- Standing pilot light design provides a ready flame when heat is required.
- Stainless steel front, door, sides and splash back.
CONTROLS
- Solstice burner/baffle design.
- Increases cooking production
- Lowers flue temperature
- Improves working environment
- Generates more production per BTU
- Thermostat maintains selected temperature automatically between 200F (93C) and 400F (190C).
- Integrated gas control valve acts as a manual and pilot valve, automatic pilot valve, gas filter, pressure regulator, and automatic main valve.
- Gas control valve prevents gas flow to the main burner until pilot is established and shuts off all gas flow automatically if the pilot flame goes out.
- Temperature limit switch safely shuts off all gas flow if the fryer temperature exceeds the upper limit.
OPERATIONS
- Front 1-1/4″ NPT drain valve, for quick draining
| Specifications | |
|---|---|
| Model | VF65 |
| Width | 19.63 inches |
| Depth | 34 inches |
| Height | 47.25 inches |
| Cooking Area | 18 x 17.3 inches |
| Cooking Depth | 4 inches |
| Power Type | Liquid Propane |
| Total BTU | 95,000 BTU/hr |
| Oil Capacity | 65 lb / 29.4 kg |
| Number of Baskets | 2 |
| Legs | 9 inches |
| Temperature Range | 200F – 400F / 93C – 190C |
| Material | Stainless Steel |
| Gas Inlet Size | 3/4 inch |
| Type | Gas Fryer |
