Description
EXTERIOR CONSTRUCTION
- Full angle-iron frame
- Stainless steel front, top, and sides
- Dual pane thermal glass windows encased in stainless steel door frames
- Powder coated door handle with simultaneous door operation
- Triple-mounted pressure lock door design with turnbuckle assembly
- Removable front control panel
- Solid mineral fiber insulation at top, back, sides and bottom
INTERIOR CONSTRUCTION
- Double-sided porcelainized baking compartment liner (14 gauge)
- Aluminized blower wheel
- Five chrome-plated racks, eleven rack positions with a minimum of 1-5/8 (41mm) spacing
OPERATION
- Three tubular heaters
- Solid state thermostat with temperature control range of 200F (93C) to 500F (260C)
- Two speed fan motor
- 1/2 horsepower blower motor with automatic thermal overload protection
- Control area cooling fan
- Interior oven lights
STANDARD FEATURES
- SSI-D – solid state infinite control w/digital timer
- 25 (635mm) adjustable stainless steel legs (for single units)
- 6 (152mm) adjustable stainless steel legs (for double sections)
| Specifications | |
|---|---|
| Model | ZEPH-200-E-DBL |
| Length | 36.9 Inches |
| Width | 38.25 Inches |
| Height | 57 Inches |
| Number of Decks | 2 |
| Number of Doors | 4 |
| Number of Racks | 10 |
| Voltage | 208 Volts |
| Amperage | 31 Amps |
| Wattage | 22 kW |
| Hertz | 60 Hz |
| Phase | 3 pH |
| Temperature Range | 200 – 500F / 93 – 260C |
| Display Type | Analog |
| Material | Stainless Steel |
| Product Type | Convection Oven |
- NSF Certified This item meets NSF’s standards that focuses on public health protection, ensuring the item is designed and constructed in a way that promotes food safety.
- CE Certified This item has been assessed and meets health, safety, and environmental requirements set by CE.
- Energy Star Partner This item meets strict energy performance standards set by EPA. Highly energy efficient making it less expensive to operate.
- ETL Sanitation List This item demonstrates compliance to North American sanitation standards
