Description
- xterior Construction – Full angle-iron frame
- Stainless Steel front top, and sides
- Dual pane thermal glass windows encased in stainless steel door frames
- Powder coated door handle with simultaneous door operation
- Triple-mounted pressure lock door design with turnbuckle assembly
- Removable front control panel
- Solid mineral fiber insulation at top, back, sides and bottom
- Interior construction – Double-Sided porcelainized baking compartment liner
- Aluminized blower wheel
- Five chrome plated racks, eleven rack positions with a minimum of 1-5/8″ spacing
- Control area cooling fan
Description
Full angle-iron frame Stainless steel front, top, and sides Dual pane thermal glass windows encased in stainless steel door frames Powder coated door handle with simultaneous door operation Triple-mounted pressure lock door design with turnbuckle assembly Removable front control panel Solid mineral fiber insulation at top, back, sides and bottom
Double-sided porcelainized baking compartment liner (14 gauge) Aluminized blower wheel Five chrome-plated racks, eleven rack positions with a minimum of 1-5/8 (41mm) spacing
Three tubular heaters Solid state thermostat with temperature control range of 200F (93C) to 500F (260C) Two speed fan motor 1/2 horsepower blower motor with automatic thermal overload protection Control area cooling fan Two interior oven lamps
Read moreSpecifications
| Specifications | |
|---|---|
| Model | ZEPH-100-E-SGL |
| Length | 38.25 inches |
| Width | 36.87 inches |
| Height | 57 inches |
| Weight | 450 Lbs |
| Number of Decks | 1 |
| Number of Doors | 2 |
| Number of Racks | 5 |
| Voltage | 208 Volts |
| Amperage | 51 Amps |
| Wattage | 11 kW |
| Hertz | 60 Hertz |
| Phase | 1 Phase |
| Connection | Hard Wire |
